Specifications

Reduction (make and model) Twin Disc MGx5225DC,

Ratio 4.59:1

FUEL TANKS AND FUEL PIPING

(a) Fuel Tank: -------------------------------------------- 4 tanks 15000 litres Total

(b) Fuel Lines: -------------------------------------------- ¾”

(c) Valve: -------------------------------------------------- Bronze ball valve

(d) Manual Shut Off: ----------------------------------- Yes

(e) Racor: ------------------------------------------------- Double 1000, 2 - 90

5 Number of Watertight Bulkheads

HYDRAULICS Size and type

(a) Hydraulic pump: ------------------------------------ 2-40 gals , 2 -15 gals Demand

(b) Hydraulic tank----------------------------------------1000 gal steel

(c) Elec. Clutch: ----------------------------------------- n/a

(d) Bracket: ----------------------------------------------- Steel

(e) Driveline: --------------------------------------------- Gear box Twin Disc

(f) Oil Cooler--------------------------------------------- 1

Safety Equipment

SAFETY EQUIPMENT

(a) Life ring: ---------------------------------- 2 -30” c/w bracket and rope

(b) Lifebuoy Light: --------------------------- 1

(c) Lifejackets--------------------------------- 8

(d) Immersion suit: -------------------------- 8

(e) P.F.D.--------------------------------------- 8

(f) Ovatek: ------------------------------------ 1 – 7 person

(g) Life raft: ----------------------------------- 6 man

(h) Eprid: -------------------------------------- 1

(i) Anchor: ------------------------------------ 1 -c/w rope and chain

(j) Radar Reflector: ------------------------- 1

(k) Fire Axe: ----------------------------------- 1

(l) Hand pump: ------------------------------ 1

(m)Horn: --------------------------------------- 1 -

(n) Rocket flares: ----------------------------- 12

(o) Handheld flares: ------------------------- 12

(p) Fire bucket--------------------------------- 2 -c/w rope

(q) Shutters for windows: ------------------ Yes

Electronics

ELECTRONIC EQUIPMENT: MAKE AND MODEL

(a) Radar: -------------------------------------- 2 - Furuno

(b) Sounder: ----------------------------------- 1 – Koden, 1- Hondex HE-7300 D1

(c) Plotter: ------------------------------------- 1 Furuno Nor net

(d) VHF: ---------------------------------------- ICOM 1C-M506, ICOM IC -M504

(e) S.S.B.---------------------------------------- N/A

(f) GPS: ---------------------------------------- Furuno GP-39

(g) Computer: --------------------------------- Complete Olex , Complete Time Zero

(h) Autopilot: ---------------------------------- Simrad AP-70

(i) Stereo: -------------------------------------- 1

(j) A.1.S----------------------------------------- 1 – ICOM MA 510TR

(k) Bilge Alarm: ------------------------------ 4

(l) Fume Alarm: ----------------------------- 4

(m)Watch Alarm: ---------------------------- 1 – Ocean Wake

(n) Forecaster: -------------------------------- 1 – Furuno NX-300

(o) Compass: ---------------------------------- 4” Ritchie

(p) Others: ------------------------------------- Standard Horizon Loud |Hailer VLH-3000

(q) VMS------------------------------------------ Sasco

Engine

Make and Model: Mitsubishi

960 HP @ 1850 RPM

2693 hrs

Cooling System: ------------------------ Keel Cooled ( Fenstrem coolers)

(i) Exhaust (Size and material) --------- 10” s/s

(j) Engine Controls: ------------------------Twin Disc Quick shaft

(k) Generator: ------------------------------ Kohler 65 Kw

(l) Aux Engine: ----------------------------- Cummins 60K and hydraulic pump driv

Cuddy

5 BUNKS IN CREW ROOM FRONT OF VESSEL ,1 SKIPPERS ROOM THEN A BUNK IN WHEELHOUSE

COOKING AND HEATING IN KITCHEN AND THROUGH OUT BOAT

Type

(a) Galley Stove: ------------------------------ 1 – Electric 240V

(b) Furnace: ----------------------------------- N/A

(c) Refrigerator: ------------------------------ 1 -Electric 120 V

(d) Grill Heater-------------------------------- N/A

(e) Heaters ------------------------------------- Electric in wheelhouse , galley accommodations, engine room and lazarette

(f) Microwave--------------------------------- 1

(g) Propane Tanks:--------------------------- N/A

(h) Oil Tank -----------------------------------N/A

(i) Others --------------------------------------N/A

Part 14. FIRE EXTINGUISHERS SYSTEM Quantity & Size Type Condition

(a) Galley: ------------------------------------- 1 – 10 lbs

(b) Accommodations: ------------------------ 1- 10 lbs

(c) Wheelhouse: ------------------------------ 1 – 10 lbs

(d) Engine Room: ---------------------------- 1- 10 lbs

(e) Others: ------------------------------------- N/A

(f) E/R Smothering System: --------------- 4 Fire Pro model EP-300

Boat General

PROPULSION: (Drive train) Size and Type

(a) Propulsion Shaft: ---------------------- 5” Aquamet 22

(b) Stern Bearing: ------------------------- Steel

(c) Stuffing Box: --------------------------- Bronze gland type

(d) Stern Tube: ----------------------------- Steel

(e) Steady Bearings: ---------------------- 2 roller bearings

(f) Bulkhead Gland: ---------------------- Bronze split

(g) Propeller: ------------------------------- 56 , 4 blades MGB c/w mazed

(h) Propeller Cage-------------------------- N/A

(i) Bow Thruster---------------------------- 1 – hydraulic

(j) Stern Thruster-------------------------- 1 hydraulic

RSW SYSTEM / BILGE PIPING/ PLUMBING/

(a) Elec Pump: -------------------------------- 2 - Rule 3700

(b) Elec Washdown: ------------------------- N/A

(c) Engine Pump: ------------------ 2-2” Flomax piped for bilge, washdown, and firehose

(d) Livewell Pump: -------------------------- N/A

(e) Toilet: -------------------------------------- 2

(f) Sink: ---------------------------------------- 3 – s /s

(g) Faucet: ------------------------------------- 3 - Double

(h) Fresh Water Tank: ---------------------- 1500 litres

(i) Water pressure pump: ------------------ 1

(j) Shower: ------------------------------------ 1

(k) Shower Drain System: ------------------ 1

(l) Livewell pump:---------------------------- 4 COLD WATER SALTWATER CHILLERS
